DD84 Store/Aftermarket ECU Calibration File
DD84 FuelTech PowerFT Base Calibration FileController-Matched File
Compatibility reviewController / OS / hardware path checked where required.
Installation guidanceDD84 workflow included with supported file delivery.
No blind cross-vehicle flashStop if the required identifiers do not match.
Down Dirty 84

DD84 FuelTech PowerFT Base Calibration File

VERIFIED FILE DELIVERYCompatibility may be reviewed before the calibration file is released. This is not a universal blind-flash download.
$299.00
BEFORE YOU BUY
  • Confirm the ECM/controller family shown in this listing.
  • Be prepared to provide a stock read / OS information when DD84 requests it.
  • HP Tuners credits, unlocks, specialty cables or loaner hardware can be additional.
  • Do not use segment-swap instructions unless this exact product/application supports them.
Installation & compatibility guide →
Product details
Confirm your service.

Ask DD84 to confirm the application, selected package, timing and any additional costs before purchase. Ask DD84

Call or text 706-208-7465
PRODUCT DETAILS

MATCHED CALIBRATION SERVICE

A starting map for your supported PowerFT ECU.

FuelTech base calibration configured from the supplied engine, ECU, firmware and hardware details. It is not a finished tune.

Pre-built starting calibration file for supported FuelTech PowerFT ECUs.

Designed for FT450, FT500/FT500LITE, FT550/FT550LITE, FT600 and other PowerFT applications where the current FTManager version supports the ECU. DD84 configures the starting map around the engine, fuel, injectors, ignition, sensors, throttle type and major hardware provided with the order.

Required after checkout

  • Exact FuelTech ECU model
  • Current FTManager and ECU firmware version
  • Vehicle and engine combination
  • Injector brand, part number and total flow
  • Fuel type
  • Ignition system and trigger pattern
  • MAP, wideband and other critical sensor information
  • Throttle type: TPS/IAC or drive-by-wire
  • Transmission/control requirements
  • Complete modification list
  • Current FuelTech map if one already exists

Installation

  1. Install the FTManager version appropriate for your ECU. FuelTech notes that some older PowerFT ECUs have software-version limits.
  2. Connect the ECU by USB and read/save a backup of the current map before changing anything.
  3. Open the DD84-delivered map and verify engine setup, fuel, injectors, ignition, input/output assignments and sensor calibrations.
  4. If drive-by-wire is used, complete the FuelTech pedal/TPS calibration procedure before starting.
  5. Write the confirmed map to the ECU using FTManager.
  6. Verify all critical sensors and outputs before cranking.
  7. Start the engine, inspect fuel pressure/wideband data and perform datalog verification before load or high-RPM operation.

Compatibility note: current FuelTech documentation lists FTManager for FT600/FT550/FT500/FT500LITE/FT450, while FT500 and FT500LITE are limited to older FTManager versions. DD84 verifies the required software path before delivery.

File delivery: the completed PowerFT map is sent to the email address on the Shopify order after the required configuration information is received.

Support: downdirty84llc@gmail.com • downdirty84llc.com

Choose the right option

Confirm your vehicle, selected scope, required submissions and current timing with DD84 before purchase. For an appointment or equipment loan, availability must also be confirmed.

  • NA / Startup Base Calibration: $299.00
  • Modified / Boosted Starting Calibration: $399.00

Ask DD84 about this service

Call or text 706-208-7465. Include the product name and your vehicle or build details.
